Tesla Model S 100 kWh battery packs

None listed right now. Set an alert or ask us to find one. We hold your money until the pack arrives.

The year decides it: a Model S 100D or P100D from 2016 has the 16-module pack, and a 2021-on Long Range or Plaid has a different five-module pack.

Buying 5 or more?Get a bulk quote — matching packs, one contact, collection arranged.
  • Payment held until the pack arrives
  • 7–14 day inspection window
  • Collection arranged for you

100 kWh Model S packs

None listed

No 100 kWh packs listed right now.

Tell us your car and how many you need, and we will look for one for you. We will also tell you as soon as a matching pack is listed.

Request a batteryShow all Model S packs

For storage projects

Packs from other cars with a similar size, for second-life storage builds. We have not confirmed any of them fits your car, so do not buy one as a replacement.

Need it fitted? Find an EV garage in our directory.EV repair shops

Can't find the right pack?

Tell us the size. We'll find it.

Request a battery

Reference

Tesla Model S 100 kWh battery facts

Two packs are listed as Tesla Model S 100 kWh: the 16-module pack of 8,256 Panasonic 18650 cells in the 100D and P100D from 2016, and a different five-module pack in 2021-on Long Range and Plaid cars. The 16-module pack is liquid cooled.

Badge
Model S 100D and P100D, from 2016
Pack from 2016
16 modules, 8,256 cells (516 per module)
Cooling
Liquid (16-module pack), with two shorter, thinner coolant loops per module
2021 on
A different pack with 5 modules in Long Range and Plaid cars; Tesla does not publish its capacity
Cells
18650 cylindrical, made by Panasonic (both packs)
VIN check
The VIN does not identify the pack. On 2021-on cars the eighth character is 5 for dual motor or 6 for the tri-motor Plaid

Note: Two packs are listed as 100 kWh: the 16-module pack in the 100D and P100D, and the five-module pack in 2021-on cars. Check the model year and the label on the pack.

Note: Sources disagree on the exact capacity of both packs, so we give only the badge figure.

Built into

  • Tesla Model S 100D and P100D (from 2016): 16-module pack
  • Tesla Model S Long Range and Plaid (2021 on): five-module pack

Documents

Safety data sheet and UN38.3 test summary for this pack, on request.

Ask for documents

Each fact is confirmed by two independent sources: Tesla's annual report, emergency response guides and VIN filings (one source), US EPA and NHTSA records, and Electrek, Teslarati, InsideEVs, Green Car Reports, Road & Track, Jalopnik, Charged EVs and The Driven. Facts we could not confirm twice are left out. Checked . Sources

Questions

Buying a used Model S 100 kWh pack

Still unsure which pack is right? A specialist can check fitment with you.

Talk to a specialist

No. The 2021-on pack has five large modules against 16 in the earlier 100 kWh pack, though both use Panasonic 18650 cells. Both are often listed as 100 kWh, so check the model year.
